Security |
---|
Detection distance | 85 m |
Operating frequency | 2405 - 2425 MHz |
Connectivity technology | Wired |
Technical details |
---|
Installation height (max) | 3.5 m |
Detection angle | 180° |
Product colour | White |
Certification | EN 300440, EN 301489-1, EN 301489-51, EN 62311,
FCC 15 C, ANATEL, AS/NZS 4268, ICASA, IFETEL,
MIC, MoC, NCC, RSS-210
EN 55032 A, EN 55024, EN 61000-6-1, EN 61000-6-2,
EN 61000-6-4, FCC 15 B A,
ICES-3(A)/NMB-3(A), KC KN32 A,
RCM AS/NZS CISPR 32 A, VCCI B, EAC
IEC/EN/UL 62368-1, IEC/EN/UL 60950-22
IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14,
IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66,
IEC/EN 62262 IK08, NEMA 250 Type 4X |
Features |
---|
Installation height (max) | 3.5 m |
Detection angle | 180° |
Product colour | White |
Certification | EN 300440, EN 301489-1, EN 301489-51, EN 62311,
FCC 15 C, ANATEL, AS/NZS 4268, ICASA, IFETEL,
MIC, MoC, NCC, RSS-210
EN 55032 A, EN 55024, EN 61000-6-1, EN 61000-6-2,
EN 61000-6-4, FCC 15 B A,
ICES-3(A)/NMB-3(A), KC KN32 A,
RCM AS/NZS CISPR 32 A, VCCI B, EAC
IEC/EN/UL 62368-1, IEC/EN/UL 60950-22
IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14,
IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66,
IEC/EN 62262 IK08, NEMA 250 Type 4X |
Power |
---|
Power source type | DC |
Power consumption (typical) | 10 W |
Input voltage | 8 - 28 V |
Operational conditions |
---|
Storage temperature (T-T) | -40 - 65 °C |
Storage relative humidity (H-H) | 10 - 100% |
Operating relative humidity (H-H) | 10 - 100% |
Operating temperature (T-T) | -40 - 60 °C |
Weight & dimensions |
---|
Width | 285 mm |
Depth | 206 mm |
Height | 152 mm |
Weight | 2.4 kg |
Packaging data |
---|
Manual | Yes |
Quantity per pack | 1 pc(s) |
Colour |
---|
Product colour | White |
Certificates |
---|
Certification | EN 300440, EN 301489-1, EN 301489-51, EN 62311,
FCC 15 C, ANATEL, AS/NZS 4268, ICASA, IFETEL,
MIC, MoC, NCC, RSS-210
EN 55032 A, EN 55024, EN 61000-6-1, EN 61000-6-2,
EN 61000-6-4, FCC 15 B A,
ICES-3(A)/NMB-3(A), KC KN32 A,
RCM AS/NZS CISPR 32 A, VCCI B, EAC
IEC/EN/UL 62368-1, IEC/EN/UL 60950-22
IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14,
IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66,
IEC/EN 62262 IK08, NEMA 250 Type 4X |
Packaging content |
---|
Manual | Yes |
