| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Certification | CE, NTRA, VCCI, KC, BSMI, FCC, IC |
| Built-in light | Yes |
| Dynamic range | 120 dB |
| Design |
|---|
| Form factor | Bullet |
| Product colour | White |
| Mounting type | Wall |
| International Protection (IP) code | IP67 |
| Housing material | Metal |
| Camera |
|---|
| Minimum illumination | 0.005 lx |
| Tilt angle range | 0 - 90 ° |
| Pan range | 0 - 360 ° |
| Angle of rotation | 360 ° |
| Camera shutter speed | 1/3 to 1/10000 |
| Lens viewing angle, horizontal | 111.4 ° |
| Lens viewing angle, vertical | 58.8 ° |
| Lens viewing angle, diagonal | 134 ° |
| Number of Privacy masking areas | 4 |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 1.6 |
| Detect distance | 64 m |
| Observe distance | 27 m |
| Recognize distance | 13 m |
| Identify distance | 6 m |
| Fixed focal length | 2.8 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR/White |
| Number of illumination LEDs | 4 |
| Infra-red wavelength | 850 nm |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Mirror, Saturation, Sharpness |
| Privacy masking | Yes |
| Smart IR | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR), Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Bit rate | 6 Mbps |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Maximum resolution | 2880 x 1620 pixels |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2688 x 1520, 2880 x 1620 |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Frame rate | 30 fps |
| Total megapixels | 5 MP |
| Audio |
|---|
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Sample rate | 8 kHz |
| Built-in speaker(s) | Yes |
| Built-in microphone | Yes |
| Audio system | 2-way |
| Audio formats supported | G.711 |
| Network |
|---|
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| Storage |
|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Built-in HDD | No |
| Maximum memory card size | 512 GB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Connectivity technology | Wired |
| Security |
|---|
| Privacy protection | Yes |
| IP address filtering | Yes |
| Password protection | Yes |
| Digest authentication | Yes |
| Management features |
|---|
| Web browser | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 10.7 W |
| DC-in jack | Yes |
| DC output voltage | 12 |
| Certificates |
|---|
| Certification | CE, NTRA, VCCI, KC, BSMI, FCC, IC |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Width | 184 mm |
| Height | 74 mm |
| Length | 74 mm |
| Weight | 525 g |
| Packaging content |
|---|
| Number of cameras | 1 |
| Other features |
|---|
| Video compression formats | H.264, H.264+, H.265, H.265+ |
