| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Processor model | ARM Cortex-A7 |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Day/night mode | Yes |
| Cable length | 0.3 m |
| Built-in processor | Yes |
| Design |
|---|
| Weatherproof | Yes |
| IK code | IK04 |
| Form factor | Turret |
| Product colour | Black |
| Mounting type | Ceiling/wall |
| Protection features | Tamper resistant, UV resistant |
| International Protection (IP) code | IP66 |
| Housing material | Aluminium, Polycarbonate (PC) |
| Camera |
|---|
| Lens viewing angle, horizontal | 102.4° |
| Lens viewing angle, vertical | 54.9° |
| Lens viewing angle, diagonal | 120.6° |
| Image sensor |
|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.4 mm (1 / 2.4") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Colour depth, Contrast, DNR, Sharpness |
| Text caption overlay | Yes |
| Privacy masking | Yes |
| Noise reduction technology | 2D noise reduction, 3D noise reduction |
| Maximum resolution | 2688 x 1512 pixels |
| Video formats supported | H.264 |
| Frame rate | 30 fps |
| Total megapixels | 4 MP |
| Audio |
|---|
| Built-in microphone | Yes |
| Network |
|---|
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Storage |
|---|
| Built-in HDD | No |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Management features |
|---|
| Reset button | Yes |
| Power |
|---|
| Power source type | PoE |
| AC input voltage | 37 - 57 V |
| Power consumption (typical) | 4 W |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 50 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Weight & dimensions |
|---|
| Height | 71.2 mm |
| Diameter | 9 cm |
| Weight | 330 g |
| Cable length | 0.3 m |
| Sustainability |
|---|
| Sustainability compliance | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Packaging content |
|---|
| Number of cameras | 1 |
| Screws included | Yes |
| Mounting kit | Yes |
| Cables included | LAN (RJ-45) |
| Technical details |
|---|
| Sustainability compliance | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
