Performance |
---|
Infrared (IR) cut-off filter | Yes |
Processor model | ARM Cortex-A7 |
Type | IP security camera |
Connectivity technology | Wired |
Placement supported | Indoor & outdoor |
Day/night mode | Yes |
Cable length | 0.3 m |
Built-in processor | Yes |
Design |
---|
Weatherproof | Yes |
IK code | IK04 |
Form factor | Turret |
Product colour | Black |
Mounting type | Ceiling/wall |
Protection features | Tamper resistant, UV resistant |
International Protection (IP) code | IP66 |
Housing material | Aluminium, Polycarbonate (PC) |
Camera |
---|
Lens viewing angle, horizontal | 102.4° |
Lens viewing angle, vertical | 54.9° |
Lens viewing angle, diagonal | 120.6° |
Image sensor |
---|
Sensor type | CMOS |
Optical sensor size | 25.4 / 2.4 mm (1 / 2.4") |
Number of sensors | 1 |
Lens system |
---|
Number of lenses | 1 |
Night vision |
---|
Night vision | Yes |
Night vision distance | 30 m |
LED type | IR |
Video |
---|
Noise reduction | Yes |
Image quality adjustment | Brightness, Colour depth, Contrast, DNR, Sharpness |
Text caption overlay | Yes |
Privacy masking | Yes |
Noise reduction technology | 2D noise reduction, 3D noise reduction |
Maximum resolution | 2688 x 1512 pixels |
Video formats supported | H.264 |
Frame rate | 30 fps |
Total megapixels | 4 MP |
Audio |
---|
Built-in microphone | Yes |
Network |
---|
Bluetooth | No |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Wi-Fi | No |
Storage |
---|
Built-in HDD | No |
Ports & interfaces |
---|
Ethernet LAN (RJ-45) ports | 1 |
Connectivity technology | Wired |
Management features |
---|
Reset button | Yes |
Power |
---|
Power source type | PoE |
AC input voltage | 37 - 57 V |
Power consumption (typical) | 4 W |
Operational conditions |
---|
Operating temperature (T-T) | -30 - 50 °C |
Operating relative humidity (H-H) | 0 - 90% |
Weight & dimensions |
---|
Height | 71.2 mm |
Diameter | 9 cm |
Weight | 330 g |
Cable length | 0.3 m |
Sustainability |
---|
Sustainability compliance | Yes |
Compliance certificates | CE, Federal Communications Commission (FCC) |
Packaging content |
---|
Number of cameras | 1 |
Screws included | Yes |
Mounting kit | Yes |
Cables included | LAN (RJ-45) |
Technical details |
---|
Sustainability compliance | Yes |
Compliance certificates | CE, Federal Communications Commission (FCC) |
