LEDware LED Driver Power Supply Constant Voltage 240V to 12V 10W 800mA EMC SAA Non-Dimmable Int Use
LED-DRV-INT-10W
Description
A LED driver is a self-contained power supply that has outputs matched to the electrical characteristics of your LED or array of LEDs. There are currently no industry standards, so understanding the electrical characteristics of your LED or array is critical in selecting or designing a driver circuit. Drivers should be current-regulated (deliver a consistent current over a range of load voltages). Drivers may have more than one channel for separate control of different LEDs or arrays.
Features:
- Independent LED driver
- Over load protection
- Output short circuit protection
- 1.0KV surge protection
- Compliance with Safty standard--EN61347-2-13/UL1310&UL8750
- Compliance with EMC standard--EN55015/FCC Part15 class A
- 5 Years warranty
Specifications:
- Input voltage range:100V-240VAC 50/60Hz
- Input currency:0.06A@240V
- Power factor:0.5 typ
- Output voltage:constant voltage 12V
- Output current:Max 0.83A
- Output load:Max. 10W
- Output Min load:1 W
- Operating Temp.(ta):-100C to 500C
- Case Temp.(tc): Max 800C
- Size(LXWXH):124cm X 39mm X 24mm
