| Technical details |
|---|
| International Protection (IP) code | IP65 |
| Voice codecs | G.711, G.722, G.729 |
| Built-in speaker(s) | Yes |
| Built-in microphone | Yes |
| IK code | IK08 |
| Memory card slot | Yes |
| Compatible memory cards | SD |
| Speaker power | 4 W |
| Number of speakers | 2 |
| Colour | Yes |
| Connectivity technology | Wired |
| Volume control | Yes |
| RFID reader | Yes |
| Display |
|---|
| Display technology | TFT/IPS |
| Display resolution | 1280 x 800 pixels |
| Backlight display | Yes |
| Video formats supported | H.264, H.265, M-JPEG |
| Touchscreen | Yes |
| Display diagonal | 25.6 cm (10.1") |
| Wide Dynamic Range (WDR) | Yes |
| Design |
|---|
| International Protection (IP) code | IP65 |
| Smartphone support | Yes |
| IK code | IK08 |
| LED indicators | Yes |
| Product colour | Black |
| Network |
|---|
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Power over Ethernet (PoE) | Yes |
| Supported network protocols | SIP2.0, SIPS, DHCP opt. 66, SMTP, SNMP, TR069, 802.1x, RTSP, RTP, SRTP, TFTP, HTTP, HTTPS, Syslog, ONVIF |
| Networking standards | IEEE 802.3at |
| Bluetooth | Yes |
| Security algorithms | 128-bit AES, 1024-bit RSA |
| Camera |
|---|
| Viewing angle, vertical | 126° |
| Viewing angle, horizontal | 144° |
| Maximum image resolution | 2560 x 1920 pixels |
| Maximum frame rate | 30 fps |
| Maximum video resolution | 2560 x 1920 pixels |
| Night vision |
|---|
| Night vision | Yes |
| Power |
|---|
| AC adapter output voltage | 12 V |
| AC adapter output current | 4 A |
| Outdoor unit power type | DC/PoE |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Weight & dimensions |
|---|
| Width | 170 mm |
| Height | 355 mm |
| Weight | 1.95 kg |
| Packaging data |
|---|
| Indoor unit included | No |
| Outdoor unit included | Yes |
