Camera Hardware
Profile |
1/3.2 5 Megapixel CMOS
sensor |
|
|
90 feet IR illumination
distance |
|
|
Automatic Infrared-Cut
Filter module for night viewing |
|
|
Minimum
illumination: |
|
|
|
0.5 lux
(color) |
|
|
0.1 lux
(B/W) |
|
|
0 lux /
(IR-LED) |
|
Minimum object
distance: 11.8 |
|
|
2.8 to 12 mm motorized
zoom Varifocal DC Auto Iris Lens |
|
|
Aperture: F
1.8 |
|
|
Angle of
view: |
|
|
|
(H) 25 -
85 |
|
|
(V) 17 -
65 |
|
Shutter Speed: 1/2.5 to
1/10,000 |
|
|
4x digital
zoom |
|
|
|
|
|
Camera
Housing |
IP66 compliant
weatherproof housing |
|
|
Includes
sunshield |
|
|
|
|
|
Features |
Configurable image
size, quality, frame rate, and bit rate |
|
|
Time stamp and text
overlays |
|
|
3 configurable motion
detection windows |
|
|
Tamper
detection |
|
|
Configurable privacy
mask zones |
|
|
Configurable shutter
speed, brightness, saturation, contrast, sharpness, WDR, flip and
mirror |
|
|
|
|
|
Video
Compression |
Simultaneous
H.264/MJPEG format compression |
|
|
Multicast
streaming |
|
|
JPEG for still
images |
|
|
|
|
|
Video
Resolution |
16:9 - 1920 x 1080,
1280 x 720, 960 x 540 at up to 30 fps |
|
|
4:3 - 2560 x 1920, 2048
x 1536, 1600 x 1200, 1280 x 960 at up to 15 fps |
|
|
|
|
|
Audio
Support |
AAC |
|
|
G.711 |
|
|
|
|
|
External Device
Interface |
10/100 BASE-TX Ethernet
port with PoE |
|
|
1 DI / 1
DO |
|
|
Reset
button |
|
|
Video Out
(BNC) |
|
|
microSD card Slot
(SD/SDHC) |
|
|
Audio input /
output |
|
|
|
|
|
Network |
|
|
|
Network
Protocols |
IPv6 |
|
|
IPv4 |
|
|
TCP/IP |
|
|
UDP |
|
|
ICMP |
|
|
DHCP
client |
|
|
NTP client
(D-Link) |
|
|
DNS
client |
|
|
DDNS client
(D-Link) |
|
|
SMTP
client |
|
|
FTP
client |
|
|
HTTP /
HTTPS |
|
|
Samba
client |
|
|
PPPoE |
|
|
UPnP port
forwarding |
|
|
RTP / RTSP/
RTCP |
|
|
IP
filtering |
|
|
QoS |
|
|
CoS |
|
|
Multicast |
|
|
ONVIF
compliant |
|
|
SNMP |
|
|
|
|
|
Security |
Administrator and user
group protection |
|
|
Remote client access
control |
|
|
HTTP and RTSP
authentication |
|
|
HTTPS encryption for
web access |
|
|
|
|
|
System
Management |
|
|
|
System Requirements
for Web Interface |
Browser: Internet
Explorer 8 or higher, Firefox, Chrome,
Safari |
|
|
|
|
|
Event
Management |
Motion
detection |
|
|
Event notification and
uploading of snapshots/video clips via e-mail or FTP |
|
|
Supports multiple HTTP,
SMTP and FTP servers |
|
|
Multiple event
notifications |
|
|
Multiple recording
methods for easy backup |
|
|
|
|
|
Remote
Management |
Take snapshots/video
clips and save to local hard drive |
|
|
Configuration interface
accessible via web browser |
|
|
|
|
|
OS Support (for
setup utility) |
Operating System:
Windows 8/7/Vista |
|
|
|
|
|
D-ViewCam System
Requirements |
Operating System:
Microsoft Windows 8/7/Vista |
|
|
Web Browser: Internet
Explorer 8 or higher |
|
|
Protocol: Standard
TCP/IP |
|
|
|
|
|
D-ViewCam Software
Functions |
Remote
management/control of up to 32 cameras |
|
|
Supports all management
functions provided in web interface |
|
|
Viewing of up to 32
cameras on one screen |
|
|
Scheduled motion
triggered, or manual recording options |
|
|
|
|
|
General |
|
|
|
Weight |
2.75 lbs (1.25
kg) 5% for camera only, without sunshield and mounting
bracket |
|
|
|
|
|
Power |
External power adapter:
12 V DC 1.5 A. 50/60 Hz, IEEE |
|
|
PoE: 802.3af Class
0 |
|
|
|
|
|
Power
Consumption |
Max: 12.48
W |
|
|
|
|
|
Temperature |
Operating: -40 to 122 F
(-40 to 50 C) |
|
|
Storage: -4 to 158 F
(-20 to 70 C) |
|
|
|
|
|
Humidity |
Operating: 20% to 80%
non-condensing |
|
|
Storage: 5% to 95%
non-condensing |
|
|
|
|
|
Certifications |
CE |
|
|
CE
LVD |
|
|
ICES-003 |
|
|
FCC |
|
|
C-Tick |
|
