Sensor

1/2.7" CMOS

Display Resolution

4.0 megapixel (2304x1536)

Min. Illumination

0 Lux (met IR Verlichting)

Optical zoom

4x

Lens Type

f:2.8~12mm,F:1.4-2.8

Angle of view

Horizontal:32 ~ 100, Diagonal : 40 ~ 130

PT

Pan/Tilt angle: H=350, V=85

Image compression

H.264

Image Frame Rate

20fps, downward adjustable

Resolution

4MP(2304x1536) 20fps,3MP(2304x1296)25fps,1080P(1920x1080) 25fps,720P(1280 x 720), VGA(640 x 480)

Stream

Dual stream

Image adjustment

The hue, brightness, contrast, saturation, sharpness are adjustable

Infrared Mode

Automatic or manual

WDR

Improve image clarity in complex scenario

Night vision

20m, IR-LED: 2 pcs

Audio in/out

Yes

2-way audio

Yes

Storage

Micro SD card (max 128GB), local & FTP storage, NVR & Cloud Storage

Ethernet

One 10/100Mbps RJ45 port

Wireless standard

IEEE802.11b/g/n/ac

Wireless security

WPA, WPA2

Network Protocol

IP, TCP, UDP, HTTP, HTTPS, SMTP, FTP, DHCP, RTSP, ONVIF

Browser

IE, Safari, Chrome

Human Detection

Yes

Motion detection

Yes

Amazon Alexa

Yes

Google Assistant

Yes

Homey

Yes

Privacy zone

N/A

User accounts

Three levels user role

IP Filtering

Yes

Reset

Reset button available

Power supply

DC 12V/2.0A

Power consumption

<20W

Dimensions (LxBxH)

108 x 108 x 102 mm

Net Weight

518g

Waterproof

IP66

Vandal-proof

IK10

Operating temperature

-20C~50C

Operating humidity

20%~85% (non-condensing)

Storage temperature

-20C~50C

Storage humidity

0%~90% (non-condensing)

Certification

CE, RoHS, FCC, WEEE
