Vivotek FD8154V Fixed Dome Network Camera - 1.3 Megapixel CMOS Sensor, 30 FPS @ 1280x1024, Real-Time H.264, MJPEG Compression (Dual Codec), Removable IR-Cut Filter For Day & Night Function - White
1.3MP SNV Day & Night 20M IR IP66 IK10 3DNR Fixed Dome Network Camera FD8154V
VIVOTEK FD8154V is a compact fixed dome network camera with 1.3-Megapixel resolution and the ability to output 30 frames per second in H.264 compression. It includes multiple streams with different settings and applications, such as recording or live viewing, delivering excellent image quality during both daytime and nighttime.
Equipped with SNV (Supreme Night Visibility) technology, the FD8154V offers increased sensitivity to low light and provides clear images in dark conditions. In addition, built-in IR LEDs enables the camera to provide enough illumination for clear viewing up to 20 meters, even in completely dark environments.
Users can also benefit from simple installation with the compact housing and standard PoE power input design, as well as an SD card slot for local storage use.
Additionally, the FD8154V is an outdoor-ready camera with an IP66-rated weatherproof and IK10-rated vandal-proof housing for increased camera protection. With all of these features and more, the FD8154V is an ideal solution for megapixel surveillance needs.
Features
- 1.3-Megapixel CMOS Sensor
- 30 fps @ 1280x1024
- Real-time H.264, MJPEG Compression (Dual Codec)
- Removable IR-cut Filter for Day & Night Function
- Built-in IR Illuminators, Effective up to 20 Meters
- Built-in 802.3af Compliant PoE
- Build-in MicroSD/SDHC/SDXC card slot for On-board Storage
- Supports ONVIF Standard to Simplify Integration and Enhance Interoperability
- Vandal-proof IK10-rated and Weather-proof IP66-rated Housing
- 3D Noise Reduction
- Supreme Night Visibility
- Selectable Lens
These specifications are subject to change without notice.
Specifications
System Information
| CPU |
- Multimedia SoC (System-on-Chip)
|
| Flash |
|
| RAM |
|
|
Camera Features
| Image sensor |
|
| Maximum Resolution |
|
| Lens Type |
|
| Focal Length |
- f = 2.8 mm (FD8154V-F2)
- f = 4 mm (FD8154V-F4)
|
| Aperture |
- F 2.0 (FD8154V-F2)
- F 1.6 (FD8154V-F4)
|
| Field of View |
- FD8154V-F2
- 101 (Horizontal)
- 80 (Vertical)
- 130 (Diagonal)
- FD8154V-F4
- 69 (Horizontal)
- 54 (Vertical)
- 87 (Diagonal)
|
| Shutter Time |
- 1/5 sec. to 1/32,000 sec.
|
| Day & Night |
- Removable IR-cut filter for day & night function
|
| Minimum Illumination |
- 0.08 Lux @ F1.6 , 30 IRE (Color)
- 0.06 Lux @ F1.6, 30 IRE (B/W)
- 0 Lux @ IR LED ON
|
| Pan / Tilt / Zoom |
- ePTZ
- 48x digital zoom (4x on IE plug-in, 12x built-in)
|
| IR Illuminators |
- Built-in IR illuminators, effective up to 20 meters
- IR LED*8
|
| On-board Storage |
- MicroSD/SDHC/SDXC card slot
|
|
Video
| Compression |
|
| Maximum Frame Rate |
- 30 fps @ 1280x1024 in both compression
|
| Maximum Streams |
|
| S/N Ratio |
|
| Video Streaming |
- Adjustable resolution, quality and bit rate
- Configurable video cropping for bandwidth saving
|
| Image Settings |
- Adjustable image size, quality and bit rate
- Time stamp, text overlay, flip & mirror
- Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks
- Scheduled profile settings, 3D noise reduction
|
|
Audio
| Audio Capability |
|
| Compression |
|
| Interface |
|
| Effective Range |
|
|
Network
| Users |
- Live viewing for up to 10 clients
|
| Protocols |
- IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP
|
| Interface |
- 10 Base-T / 100 BaseTX Ethernet (RJ-45)
|
| ONVIF |
- Supported, specification available at www.onvif.org
|
|
Intelligent Video
| Video Motion Detection |
- Triple-window video motion detection
|
|
Alarm and Event
| Alarm Triggers |
- Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection
|
| Alarm Events |
- Event notification using digital output, HTTP, SMTP, FTP and NAS server
- File upload via HTTP, SMTP, FTP and NAS server
|
|
General
| Connectors |
- RJ-45 for Network/PoE connection
- Digital input * 1
|
| LED Indicator |
- System power and status indicator
|
| Power input |
|
| Power consumption |
|
| Dimensions |
|
| Weight |
|
| Casing |
- Vandal-proof IK10-rated metal housing
- Weather-proof IP66-rated housing
|
| Safety Certifications |
- CE C-Tick FCC ( Class A ) LVD VCCI
|
| Operating Temperature |
- Starting Temperature: -10C ~ 50C (14F~ 122F)
- Working Temperature: -20C ~ 50C (-4F~ 122F)
|
| Warranty |
|
|
System Requirements
| Operating System |
- Microsoft Windows 7 / Vista / XP / 2000
|
| Browser |
- Mozilla Firefox 7~10 ( Streaming only )
- Internet Explorer 7.x ,8.x, 9.x, 10.x
|
| Other Players |
- VLC: 1.1.11 or above
- QuickTime: 7 or above
|
|
|
|
|
