E31
1MP Bullet with D/N, IR, Basic WDR, Fixed lens
Main Features
- Progressive Scan CMOS
- Day and night function with mechanical IR cut filter
- Minimum illumination 0 lux with IR LED on
- Built-in f4.2 mm / F1.8 Megapixel fixed lens
- 30 fps, at 1280 x 720 resolution
- Selectable H.264 HP, MJPEG compressions with dual streaming
- Video motion detection
- Basic WDR
- Weatherproof IP66 rated casing
- Powered by PoE Class 2
PRODUCT SPECIFICATION
Device Type: Bullet Camera
Image Sensor: Progressive Scan CMOS
Sensor Size: 1/'4"
Day / Night: Yes
Minimum Illumination: Color: 0.1 lux at F1.8 (30 IRE, 2400°K); B/W: 0 lux (IR LED on)
Color to B/W switch: ISP sensor based switch; Configurable
Mechanical IR Cut Filter: Yes
IR Sensitivity Range: 700 - 1100 nm
IR LED: IR LED x 20 (850 nm)
IR Working Distance: 15 m (0 lux, 30 IRE, Max Exposure Gain)
Electronic Shutter: 1/5 ~ 1/2,000 sec (manual mode); 1/5 ~ 1/10,000 sec (auto mode)
Lens
Focal Length / Aperture: Fixed focal, f4.2 mm / F1.8
Iris: Fixed iris
Focus: Fixed Focus
Lens Mount: Board Mount
Horizontal Viewing Angle: 55.9°
Video
Compression: H.264 HP, MJPEG
Maximum Frame Rate vs. Resolution: 30 fps at 1280 x 720; 30 fps at 640 x 480
Multi-Streaming: Simultaneous dual streams based on two configurations
Bit Rate: 28 Kbps - 6 Mbps (per stream)
Bit Rate Mode: Constant, Variable
Image Enhancement: Basic WDR; White balance: automatic, hold, and manual; Brightness; Contrast; Sharpness(auto); Auto gain control; Digital noise reduction; Flickerless
Privacy Mask: 4 configurable regions
Text Overlay: User defined text on video
Image Orientation: Image flip and mirror
Network
Protocol & Service: TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP,IGMP, SMTP, FTP,
UPnP, SNMP, Bonjour
Ethernet Port: 1, Ethernet (10/100 Base-T), RJ-45 connector
Security: IP address filtering; HTTPS encryption; Password protected user levels; Anonymous login; IEEE 802.1X network access control
Alarm
Alarm Trigger: Video motion detection (3 regions)
Alarm Response: Notify control center; Change camera settings; Command other devices; E-mail notification with snapshots; Upload video, snapshot to FTP server
General
Power Source / Consumption: PoE Class 2 (IEEE802.3af) / 5.41 W (IR on)
Weight: 584 g (1.29 lb)
Dimensions (Ø x L): 77 mm x 196.74 mm (3.04" x 7.7'')
Bundled Accessories: Bracket
Environmental Casing: Weatherproof (IP66 rated)
Mount Type: Wall, Ceiling, Corner, Pole
Starting Temperature: -20 °C ~ 50 °C (-4 °F ~ 122 °F)
Operating Temperature: -40 °C ~ 50 °C (-40 °F ~ 122 °F)
Operating Humidity: 10% ~ 85% RH
Approvals: CE (EN 55022 Class B, EN 55024), FCC (Part15 Subpart B Class B), IP66
Integration
Unified Solution: Fully compatible with ACTi software
ISV Integration: Software Development Kit (SDK) available; ONVIF compliant
Firmware Access Browser: Microsoft Internet Explorer 8.0 or newer (full functionality); Other browsers with VLC installed (partial functionality)
