Compro NC2200 Dome Network Camera - 2 Megapixel, 1/3" Progressive Scan CMOS Image Sensor, 10x Digital Zoom, H.264, Vandal Resistant, MicroSD/SDHC Card Slot, IP66-Rated Weatherproof Casing - White NC2200 | 2MP-IP66-POE-H.264-VANDAL-RESISTANT
Key Features
- 1/3" progressive scan CMOS image sensor
- Supports H.264, MPEG-4 and MJPEG video compression
- 10x digital zoom
- 2-Megapixel 1600 by 1200 resolution at 15 FPS
- Supports dynamic dual streaming, active bandwidth, management, activity-adaptive streaming, Quality-of-Service (QoS)
- Intelligent video analytics
- Supports SMS and E-mail notification
- microSD/SDHC memory slot for storing event snapshot and recording
- IP66-rated weatherproof casing
- 2-axis positioning (manual pan/tilt)
- Built-in microphone
Technical Specifications
|
Camera
|
| Indoor / Outdoor |
Indoor & Outdoor |
| Sensor |
1/3" CMOS 2-Megapixel sensor |
| Lens |
Fixed iris, F 2.0, f 1.96mm |
| Zoom |
10x digital |
| Angle of View |
105 |
| Min Illumination |
1.0 lux |
| Shutter Time |
1/5 ~ 1/16000 Sec. |
| Camera Angle Adjustment |
40 pan, 90 tilt
|
|
Video
|
| Video Format |
M-JPEG, MPEG-4, H.264 |
| Resolutions |
160x120, 320 x 240, 640 x 480, 1280 x 1024, 1600 x 1200 |
| Frame Rate |
Turbo picture mode:1600 x1200 up to 15 FPS
Motion adaptive mode: HDTV 720P (1280 x 720) up to 30 FPS; VGA or below up to 30 FPS
|
| Video Streaming |
Dual video stream supported |
| Dynamic Control |
Active bandwidth management, activity adaptive streaming
|
| Image Settings |
Adjustable image size and quality
AGC, AWB, AES
Configurable brightness, saturation and sharpness
|
|
Audio
|
| Compression Format |
G.711 PCM 64 Kbit/sec |
| Audio Input / Output |
Built-in microphone |
|
System Integration
|
| Intelligent Analytics |
Motion detection, tampering detection, loitering detection, audio detection, multi-zone/sensitivity |
| Triggering Event |
Analytics, schedule, network failure |
| Triggering Reaction |
SMS, snapshot, local/remote recording, e-mail, FTP, alarm output, ComproView notification
|
| SDK |
Yes |
|
Local Storage
|
| Local Storage |
Built-in microSD memory slot (with a pre-installed 4GB memory card) |
| Format |
AVI (audio incl.), by events or schedule; JPEG, file name format customizable |
|
Network
|
| Protocols |
3GPP, ARP, DDNS, DHCP, DNS, FTP, HTTP, ICMP/IPv4, IGP, NTP, PPPoE, QoS, RSP, RTSP, SMTP, TCP/IP, UDP, UPnP |
| Ethernet |
10/100 Base-T, auto-sensing, RJ-45 |
| User Group |
2 levels, unlimited users, ID/password protected, max 10 simultaneous users
|
| Diagnostics |
Auto connectivity diagnosis, auto bandwidth detection, iWizard |
|
Remote Surveillance
|
| Mobile Surveillance |
M-JPEG, 3GPP over Android, BlackBerry, iPhone, Windows Mobile (features vary) |
| Web Surveillance |
16-CH WebVUer over Internet Explorer, Chrome, Firefox, Safari (features vary) |
|
General
|
| Unit Configuration |
Rebooting, factory default, date/time synchronization, user profile management, firmware upgrade, OSD, multilingual UI |
| User Authentication |
ID, password |
| Frame Rate |
HTTP mode
|
| OSD |
Text or image overlay, 4 locations |
| Language |
Chinese Traditional, Chinese Simplified, German, Spanish, English, Japanese, Portuguese, Russian, Turkish, Ukrainian, Bulgarian
|
| Regulatory |
CE, FCC
|
|
Mechanical
|
| Weather Resistance |
IP66 |
| Dimensions |
103mm x 100 x 56 mm (L x W x H) |
| Weight (Net) |
270g
|
|
Electrical
|
| Input Voltage |
PoE (Power-over-Ethernet) only |
| PoE |
IEEE 802.3af Class 3 |
|
Environmental
|
| Operating Temperature |
-20~ 50 C / -4 ~ 122 F |
| Humidity |
20~80% RH non-condensing |
|
Browsing Requirement
|
| OS |
Microsoft Windows XP SP3, Vista SP1, 7 (x86/x64) |
| Processor |
Intel 2.8 GHz, 2GB RAM |
| Web Browser |
Microsoft Internet Explorer 8.0 or above, non-IE browsers require 3rd-party VLC plugin
|
|
|
|
