Vivotek FD8131V Fixed Dome Network Camera - 1 Megapixel CMOS Sensor, 3.0~12mm Vari-Focal Lens, Real-Time H.264, MPEG-4 & MJPEG Compression (Triple Codec), Weather-Proof IP66-Rated Housing - White
1MP Vari-focal Lens Vandal-proof Compact Design Fixed Dome Network Camera FD8131V
Overview
VIVOTEK FD8131V are easy-to-use fixed dome network cameras specifically designed for indoor security applications. Equipped with a 1MP sensor enabling viewing resolution of 1280x800 at 30 fps, users need to look no further for an all-in-one camera capable of capturing high quality HD video.
With the vari-focal lens, the FD8131V provide users the freedom to adjust the field of view in accordance with their applications. The IP66-rated housing of FD8131V protects the camera body against rain and dust and ensures operation under poor weather conditions. Furthermore, the metal vandal-proof housing effectively provides robust protection of FD8131V from vandalism.
Also included are a number of advanced features standard on VIVOTEK cameras, including tamper detection, MicroSD/SDHC card slot, 802.3af compliant PoE, and VIVOTEK's 32-channel recording software. With all of these capabilities, the FD8131V present the best value in IP surveillance for indoor applications.
Features
- 1-megapixel CMOS Sensor
- 3.0 ~ 12 mm Vari-focal Lens
- Real-time H.264, MPEG-4 and MJPEG Compression (Triple Codec)
- Built-in 802.3af Compliant PoE
- Built-in MicroSD/SDHC Card Slot for On-board Storage
- 3-axis Mechanical Design for Ceiling/Wall Mount Installation
- Easy and Flexible Installation
- Compact, Elegant Design
- Vandal-proof IK10-rated and Weather-proof IP66-rated Housing
Specifications:
System Information
| CPU |
- Multimedia SoC (System-on-Chip)
|
| Flash |
|
| RAM |
|
|
Camera Features
| Image sensor |
|
| Maximum Resolution |
1280x800
|
| Lens Type |
|
| Focal Length |
|
| Aperture |
|
| Shutter Time |
- 1/5 sec. to 1/32,000 sec.
|
| Minimum Illumination |
|
| Pan / Tilt / Zoom |
- ePTZ: 16x digital zoom (4x on IE plug-in, 4x built-in)
|
| On-board Storage |
MicroSD/SDHC card slot
|
|
Video
| |
|
| Maximum Frame Rate |
|
| Maximum Streams |
|
| S/N Ratio |
|
| Dynamic Range |
|
| Video Streaming |
- Adjustable resolution, quality and bitrate/li>
- Configurable video cropping for bandwidth saving
|
| Image Settings |
- Adjustable image size, quality and bit rate
- Time stamp, text overlay, flip & mirror
- Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks
- Scheduled profile settings
|
|
Audio
| |
- 10Base-T/100 BaseTX Ethernet (RJ-45)
|
|
Network
| Users |
- Live viewing for up to 10 clients
|
| |
- LPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X
|
| ONVIF |
|
|
Intelligent Video
| Video Motion Detection |
- Triple-window video motion detection
|
|
Alarm and Event
| Alarm Triggers |
- Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection
|
| Alarm Events |
- Event notification using digital output, HTTP, SMTP, FTP and NAS server
- File upload via HTTP, SMTP, FTP and NAS server
|
|
General
| Connectors |
- RJ-45 cable connector for Network/PoE connection
- Digital input*1
- DC 12V power input
|
| LED Indicator |
- System power and status indicator
|
| Power input |
- DC 12V
- IEEE 802.3af PoE Class 1
|
| Power consumption |
|
| |
|
| Weight |
|
| Safety Certifications |
- CE, LVD, FCC Class B, VCCI, C-Tick
|
| Operating Temperature |
- Start Temperature: -10C ~ 50C (14F ~ 122F)
- Working Temperature: -20C ~ 50C (-4F ~ 122F)
|
| Warranty |
|
|
System Requirements
| Operating System |
- Microsoft Windows 7/Vista/XP/2000
|
| Browser |
- Mozilla Firefox 7~10 (streaming only)
- Internet Explorer 7.x or 8.x
|
| Other Players |
- VLC: 1.1.11 or above
- Quicktime: 7 or above
|
|
|
|
|
