540 TV Lines 1/3" SONY "SuperHAD" CCD high video quality / 115ft 35m excellent night vision / Variable Focus and Optical Zoom / Weather resistant robust metal casing / 60ft 18m BNC cable / Easily connects to your TV & DVR







Expect the highest level of protection from the PRO-680 Ultimate Optical Zoom Day/Night Security Camera. Often criminals and other suspicious individuals can escape identification as they are just beyond the range of many standard security cameras that produce blurry or grainy images. The PRO-680 is our top of the range camera in the PRO-SERIES featuring a crystal clear image with the 540 Line 1/3" Sony "SuperHAD" high-resolution video sensor that will capture the finest detail.

With this state-of-the-art high-resolution video technology, you can keep a continuous eye out for thieves, vandals, break-ins or any other suspicious activity. With the powerful infrared night vision you can clearly capture crystal clear images from up to 115 feet or 35 meters away, making it an ideal security solution for a variety of retail, office, commercial and home applications. Complete with 36 infrared LEDs that switch on automatically to capture high-resolution footage at night. The 4-9mm vari-focal lens can zoom and focus on an area via the adjustable controls located on the underside of the barrel.

Everything you need is included in the pack including 60ft 18m BNC cable for connecting to a DVR and power, BNC to RCA connector for connecting to a TV, power adapter, user guide, deterrent security stickers and more. When combined with a Swann DVR you'll be able to record, store, and remotely view footage online for total peace of mind. Best of all, their "plug & play" installation makes set-up incredibly simple, indoors and out.

The PRO-680 Ultimate Optical Zoom Day/Night Security Camera from Swann. It's advanced Security made easy.





See more with high resolution 540 TV lines SONY CCD video, powerful infrared night vision & vari-focal controls for high quality video in any light, near or far

Easily mount to walls with cable threaded through the bracket for added protection

Fight back against crime by deterring intruders & protecting your property

Plug into your DVR for recording or TV's yellow video-in socket for immediate surveillance

Perfect for home, office, retail or commercial surveillance, indoors or outdoors in any conditions

On screen display (OSD) with a variety of easy to use, customisable options





PRO-680
	Video
Image Sensor	Color 1/3" Sony 'Super HAD' CCD
Video Quality	540 TV Lines
Pixels	768 x 494 (NTSC) 752 x 582 (PAL)
Minimum Illumination	0 Lux (IR on) / 0.1 Lux (IR off)
Day/Night Mode	Color during day / switches to B&W at night
Electronic Shutter	1/60 - 1/100,000 NTSC 1/50 - 1/100,000 PAL
Gain Control	Automatic / Custom
Backlight Comopensation	Selectable
Wide Dynamic Rangel	Selectable
Lens	Vari-focal 4mm ~ 9mm
Viewing Angle	35-70 (H:30~62 V:22~48 D:37~73)
	Night Vision
Night Vision Distance	Up to 115ft / 35m
IR Cut Filter	No
Number of Infra-Red LEDs	36
Infra-Red Wavelength	850nm
Infra-Red LED Life	10,000 hrs
	General
Indoor / Outdoor	Both
Operating Power	DC 12V
Operation Temperature	-4 degrees F to 113 degrees F -20 degrees C to +45 degrees C
Body Construction	Aluminum
Camera Dimensions	10.25" x 3.25" x 6.3" 260mm x 83mm x 160mm
Camera Weight	1.90lbs / 865g
Cable Length	60ft / 18m















 Often you will find that your standard security video camera will not cover up the entire area you are trying to protect. With the PRO-660 Super Wide-Angle Day/Night Security Camera from our top of the range PRO-SERIES, you will be able to cover those larger areas with ease. The PRO-660 features a 540 Line 1/3" Sony "SuperHAD" high-resolution video sensor, combined with a super wide 75 degrees viewing angle, making it ideal for monitoring large areas such as yards, warehouses, parking lots and more. Its cutting-edge night vision can capture high-clarity images from up to 65 feet away and its durable weatherproof metal casing will withstand the elements.

Everything you need is included in the pack including 60ft 18m BNC cable for connecting to a DVR and power, BNC to RCA connector for connecting to a TV, power adapter, user guide, deterrent security stickers and more. When combined with a Swann DVR you'll be able to record, store, and remotely view footage online for total peace of mind. Best of all, their "plug & play" installation makes set-up incredibly simple, indoors and out.

The PRO-660 Super Wide-Angle Day/Night Security Camera from Swann. It's advanced Security made easy.



• Pro quality 540 TV lines for peace of mind 24/7
• See more with high resolution 540 TV Lines Sony CCD video & powerful infrared night vision
• Easily mount to walls with cable threaded through the bracket for added protection
• Fight back against crime by deterring intruders & protecting your property
• Plug into your DVR for recording or TV's yellow video-in socket for immediate surveillance
• Perfect for wide angle viewing of yards, warehouses, parking lots, driveways, alleys etc



PRO-660
	Video
Image Sensor	Color 1/3" Sony 'Super HAD' CCD
Video Quality	540 TV Lines
Pixels	768 x 494 (NTSC) 752 x 582 (PAL)
Minimum Illumination	0 Lux (IR on) / 0.1 Lux (IR off)
Day/Night Mode	Color during day / switches to B&W at night
Electronic Shutter	1/60 - 1/100,000 NTSC 1/50 - 1/100,000 PAL
Gain Control	Automatic
Backlight Comopensation	Yes
Wide Dynamic Rangel	Yes
Lens	3.6mm
Viewing Angle	75 (H:80 V:70 D:90)
	Night Vision
Night Vision Distance	Up to 65ft / 20m
IR Cut Filter	No
Number of Infra-Red LEDs	23
Infra-Red Wavelength	850nm
Infra-Red LED Life	10,000 hrs
	General
Indoor / Outdoor	Both
Operating Power	DC 12V
Operation Temperature	-4 degrees F to 113 degrees F -20 degrees C to +45 degrees C
Body Construction	Aluminum
Camera Dimensions	6.5" x 4.5" x 3.15" 165mm x 115mm x 67mm
Camera Weight	1.02lbs / 465g
Cable Length	60ft / 18m
