13/05
|
Trimmer Capacitor - 8.5 to 70pF, 250V, Black** Minimum purchase of 10 units **
D Series, top adjust, 2 pin, Colour coded for range identification.
Specifications
|
Pitch: 5.8mm
Working Voltage: 250V DC
Withstand Voltage: 550V DC
Insulation Resistance: 10G Ohm min at 250V DC
Operating Temperature: -55°C to +85°C
Q Value: >1000 at 1MHz at max setting
|
|
|
|
|
13/05
|
Trimmer Capacitor - 8.5 to 50pF, 250V, Green** Minimum purchase of 10 units **
D Series, top adjust, 2 pin, Colour coded for range identification.
Specifications
|
Pitch: 5.8mm
Working Voltage: 250V DC
Withstand Voltage: 550V DC
Insulation Resistance: 10G Ohm min at 250V DC
Operating Temperature: -55°C to +85°C
Q Value: >1000 at 1MHz at max setting
|
|
|
|
|
13/05
|
Trimmer Capacitor - 8.5 to 40pF, 250V, Brown** Minimum purchase of 10 units **
D Series, top adjust, 2 pin, Colour coded for range identification.
Specifications
|
Pitch: 5.8mm
Working Voltage: 250V DC
Withstand Voltage: 550V DC
Insulation Resistance: 10G Ohm min at 250V DC
Operating Temperature: -55°C to +85°C
Q Value: >1000 at 1MHz at max setting
|
|
|
|
|
13/05
|
Trimmer Capacitor - 5.0 to 30pF, 250V, Yellow** Minimum purchase of 10 units **
D Series, top adjust, 2 pin, Colour coded for range identification.
Specifications
|
Pitch: 5.8mm
Working Voltage: 250V DC
Withstand Voltage: 550V DC
Insulation Resistance: 10G Ohm min at 250V DC
Operating Temperature: -55°C to +85°C
Q Value: >1000 at 1MHz at max setting
|
|
|
|
|
13/05
|
Trimmer Capacitor - 3.5 to 20pF, 250V, Blue** Minimum purchase of 10 units **
D Series, top adjust, 2 pin, Colour coded for range identification.
Specifications
|
Pitch: 5.8mm
Working Voltage: 250V DC
Withstand Voltage: 550V DC
Insulation Resistance: 10G Ohm min at 250V DC
Operating Temperature: -55°C to +85°C
Q Value: >1000 at 1MHz at max setting
|
|
|
|
|
13/05
|
Trimmer Capacitor - 3.0 to 12pF, 250V, White** Minimum purchase of 10 units **
D Series, top adjust, 2 pin, Colour coded for range identification.
Specifications
|
Pitch: 5.8mm
Working Voltage: 250V DC
Withstand Voltage: 550V DC
Insulation Resistance: 10G Ohm min at 250V DC
Operating Temperature: -55°C to +85°C
Q Value: >1000 at 1MHz at max setting
|
|
|
|
|
13/05
|
Trimmer Capacitor - 1.8 to 7pF, 250V, Red** Minimum purchase of 10 units **
D Series, top adjust, 2 pin, Colour coded for range identification.
Specifications
|
Pitch: 5.8mm
Working Voltage: 250V DC
Withstand Voltage: 550V DC
Insulation Resistance: 10G Ohm min at 250V DC
Operating Temperature: -55°C to +85°C
Q Value: >1000 at 1MHz at max setting
|
|
|
|
|
13/05
|
Bipolar Capacitor - 50V, 100uF, 16mm, PCB Mount** Minimum purchase of 10 units **
Features:
|
Radial lead
Excellent frequency characteristics
Low leakage current and low dissipation factor
Perfect for audio applications
|
Specifications
|
Tolerance: ±20%
Pitch: 7.5mm
Diameter: 16.0mm
Height: 27.0mm
Voltage: 50V DC
Ripple Current: 363mA
Temperature Range: -40°C to +85°C
|
|
|
Note: All quantities are supplied loose.
|
|
|
|
|
13/05
|
Bipolar Capacitor - 50V, 47uF, 13mm, PCB Mount** Minimum purchase of 10 units **
Features:
|
Radial lead
Excellent frequency characteristics
Low leakage current and low dissipation factor
Perfect for audio applications
|
Specifications
|
Tolerance: ±20%
Pitch: 5.0mm
Diameter: 13.0mm
Height: 21.0mm
Voltage: 50V DC
Ripple Current: 640mA
Temperature Range: -40°C to +85°C
|
|
|
Note: All quantities are supplied loose.
|
|
|
|
|
13/05
|
Bipolar Capacitor - 50V, 22uF, 10mm, PCB Mount** Minimum purchase of 10 units **
Features:
|
Radial lead
Excellent frequency characteristics
Low leakage current and low dissipation factor
Perfect for audio applications
|
Specifications
|
Tolerance: ±20%
Pitch: 5.0mm
Diameter: 10.0mm
Height: 20.0mm
Voltage: 50V DC
Ripple Current: 480mA
Temperature Range: -40°C to +85°C
|
|
|
Note: All quantities are supplied loose.
|
|
|
|
|
13/05
|
Bipolar Capacitor - 50V, 10uF, 10mm, PCB Mount** Minimum purchase of 100 units **
Features:
|
Radial lead
Excellent frequency characteristics
Low leakage current and low dissipation factor
Perfect for audio applications
|
Specifications
|
Tolerance: ±20%
Pitch: 5.0mm
Diameter: 10.0mm
Height: 16.0mm
Voltage: 50V DC
Ripple Current: 365mA
Temperature Range: -40°C to +85°C
|
|
|
Note: All quantities are supplied loose.
|
|
|
|
|
13/05
|
Bipolar Capacitor - 50V, 6.8uF, 8mm, PCB Mount** Minimum purchase of 100 units **
Features:
|
Radial lead
Excellent frequency characteristics
Low leakage current and low dissipation factor
Perfect for audio applications
|
Specifications
|
Tolerance: ±20%
Pitch: 3.5mm
Diameter: 8.0mm
Height: 11.0mm
Voltage: 50V DC
Ripple Current: 280mA
Temperature Range: -40°C to +85°C
|
|
|
Note: All quantities are supplied loose.
|
|
|
|
|
13/05
|
Bipolar Capacitor - 50V, 4.7uF, 8mm, PCB Mount** Minimum purchase of 100 units **
Features:
|
Radial lead
Excellent frequency characteristics
Low leakage current and low dissipation factor
Perfect for audio applications
|
Specifications
|
Tolerance: ±20%
Pitch: 3.5mm
Diameter: 8.0mm
Height: 11.0mm
Voltage: 50V DC
Ripple Current: 145mA
Temperature Range: -40°C to +85°C
|
|
|
Note: All quantities are supplied loose.
|
|
|
|
|
13/05
|
Bipolar Capacitor - 50V, 3.3uF, 8mm, PCB Mount** Minimum purchase of 100 units **
Features:
|
Radial lead
Excellent frequency characteristics
Low leakage current and low dissipation factor
Perfect for audio applications
|
Specifications
|
Tolerance: ±20%
Pitch: 3.5mm
Diameter: 8.0mm
Height: 11.0mm
Voltage: 50V DC
Ripple Current: 105mA
Temperature Range: -40°C to +85°C
|
|
|
Note: All quantities are supplied loose.
|
|
|
|
|
13/05
|
Bipolar Capacitor - 50V, 2.2uF, 8mm, PCB Mount** Minimum purchase of 100 units **
Features:
|
Radial lead
Excellent frequency characteristics
Low leakage current and low dissipation factor
Perfect for audio applications
|
Specifications
|
Tolerance: ±20%
Pitch: 3.5mm
Diameter: 8.0mm
Height: 11.0mm
Voltage: 50V DC
Ripple Current: 85mA
Temperature Range: -40°C to +85°C
|
|
|
Note: All quantities are supplied loose.
|
|
|
|
|
13/05
|
Bipolar Capacitor - 50V, 1.0uF, 8mm, PCB Mount** Minimum purchase of 100 units **
Features:
|
Radial lead
Excellent frequency characteristics
Low leakage current and low dissipation factor
Perfect for audio applications
|
Specifications
|
Tolerance: ±20%
Pitch: 3.5mm
Diameter: 8.0mm
Height: 11.0mm
Voltage: 50V DC
Ripple Current: 45mA
Temperature Range: -40°C to +85°C
|
|
|
Note: All quantities are supplied loose.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 16V, 470uF, Reel of 500
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 35V, 220uF, Reel of 500
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 25V, 220uF, Reel of 500
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 35V, 100F, Reel of 500
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 25V, 100uF, Reel of 1,000
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 16V, 100uF, Reel of 1,000
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 50V, 47uF, Reel of 500
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 35V, 47uF, Reel of 1,000
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 16V, 47uF, Reel of 1,000
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 35V, 22uF, Reel of 1,000
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 50V, 10uF, Reel of 1,000
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 35V, 10uF, Reel of 1,000
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 16V, 10uF, Reel of 2,000
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 50V, 4.7uF, Reel of 1,000
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 35V, 4.7uF, Reel of 2,000
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 50V, 2.2uF, Reel of 2,000
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 50V, 1uF, Reel of 2,000Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 1µF
Volts DC: 50V
Ripple: 10mA
Package (ØD xH): 4 x 5.3mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 16V, 470uF, Pack of 1Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 470µF
Volts DC: 16V
Ripple: 458mA
Package (ØD xH): 10 x 10mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 35V, 220uF, Pack of 5Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 220µF
Volts DC: 35V
Ripple: 458mA
Package (ØD xH): 10 x 10mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 25V, 220uF, Pack of 5Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 220µF
Volts DC: 25V
Ripple: 252mA
Package (ØD xH): 8 x 10mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 35V, 100uF, Pack of 5Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 100µF
Volts DC: 35V
Ripple: 252mA
Package (ØD xH): 8 x 10mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 25V, 100uF, Pack of 5Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 100µF
Volts DC: 25V
Ripple: 155mA
Package (ØD xH): 8 x 6.5mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 16V, 100uF, Pack of 5Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 100µF
Volts DC: 16V
Ripple: 103mA
Package (ØD xH): 6.3 x 5.3mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 50V, 47uF, Pack of 5Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 47µF
Volts DC: 50V
Ripple: 252mA
Package (ØD xH): 8 x 10mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 35V, 47uF, Pack of 10Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 47µF
Volts DC: 35V
Ripple: 155mA
Package (ØD xH): 8 x 6.5mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 16V, 47uF, Pack of 10Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 47µF
Volts DC: 16V
Ripple: 75mA
Package (ØD xH): 6.3 x 5.3mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 35V, 22uF, Pack of 10Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 22µF
Volts DC: 35V
Ripple: 59mA
Package (ØD xH): 6.3 x 5.3mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 50V, 10uF, Pack of 10Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 10µF
Volts DC: 50V
Ripple: 44mA
Package (ØD xH): 6.3 x 5.3mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 35V, 10uF, Pack of 10Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 10µF
Volts DC: 35V
Ripple: 34mA
Package (ØD xH): 5 x 5.3mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 16V, 10uF, Pack of 10Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 10µF
Volts DC: 16V
Ripple: 26mA
Package (ØD xH): 4 x 5.3mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 50V, 4.7uF, Pack of 10Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 4.7µF
Volts DC: 50V
Ripple: 26mA
Package (ØD xH): 5 x 5.3mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 35V, 4.7uF, Pack of 10Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 4.7µF
Volts DC: 35V
Ripple: 20mA
Package (ØD xH): 4 x 5.3mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 50V, 2.2uF, Pack of 10Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 2.2µF
Volts DC: 50V
Ripple: 15mA
Package (ØD xH): 4 x 5.3mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Electrolytic Capacitor - 50V, 1.0uF, Pack of 10Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
Features:
|
Recommended for reflow or hand soldering
85°C, 2000 hours assured life
Temperature range -40° to +85°C
Tolerance: ±20%
|
Specifications:
|
Value: 1µF
Volts DC: 50V
Ripple: 10mA
Package (ØD xH): 4 x 5.3mm
NOTE:
Due to continued product development, specifications are subject to change without prior notice.
|
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 16V, 22uF, Reel of 2,000Supplied in conventient 10 piece packs for servicing and prototying and in a 2000 piece bulk reel for production.
Size: 3.2L x 1.6W x 1.6H
Features:
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Tolerance: ±20%
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 16V, 10uF, Reel of 2,000Supplied in conventient 10 piece packs for servicing and prototying and in a 2000 piece bulk reel for production.
Size: 3.2L x 1.6W x 1.6H
Features:
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Tolerance: ±20%
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 10V, 10uF, Reel of 2,000Supplied in conventient 10 piece packs for servicing and prototying and in a 2000 piece bulk reel for production.
Size: 3.2L x 1.6W x 1.6H
Features:
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Tolerance: ±20%
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 20V, 4.uF, Reel of 2,000Supplied in conventient 10 piece packs for servicing and prototying and in a 2000 piece bulk reel for production.
Size: 3.2L x 1.6W x 1.6H
Features:
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Tolerance: ±20%
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 16V, 4.7uF, Reel of 2,000Supplied in conventient 10 piece packs for servicing and prototying and in a 2000 piece bulk reel for production.
Size: 3.2L x 1.6W x 1.6H
Features:
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Tolerance: ±20%
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 25V, 2.2uF, Reel of 2,000Supplied in conventient 10 piece packs for servicing and prototying and in a 2000 piece bulk reel for production.
Size: 3.2L x 1.6W x 1.6H
Features:
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Tolerance: ±20%
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 20V, 2.2uF, Reel of 2,000Supplied in conventient 10 piece packs for servicing and prototying and in a 2000 piece bulk reel for production.
Size: 3.2L x 1.6W x 1.6H
Features:
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Tolerance: ±20%
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 35V, 1.0uF, Reel of 2,000Supplied in conventient 10 piece packs for servicing and prototying and in a 2000 piece bulk reel for production.
Size: 3.2L x 1.6W x 1.6H
Features:
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Tolerance: ±20%
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 35V, 0.47uF, Reel of 2,000Supplied in conventient 10 piece packs for servicing and prototying and in a 2000 piece bulk reel for production.
Size: 3.2L x 1.6W x 1.6H
Features:
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Tolerance: ±20%
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 16V, 22uF, Pack of 10SMD Tantalum Capacitor
Features:
|
Suitable for reflow or hand soldering
Temperature range -55° to +125°C
Tolerance: ±20%
|
Specifications:
|
Value: 22µF
Volts DC: 16V
Package: B
|
NOTE:
|
|
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 16V, 10uF, Pack of 10SMD Tantalum Capacitor
Features:
|
Suitable for reflow or hand soldering
Temperature range -55° to +125°C
Tolerance: ±20%
|
Specifications:
|
Value: 10µF
Volts DC: 16V
Package: B
|
NOTE:
|
|
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 10V, 10uF, Pack of 10SMD Tantalum Capacitor
Features:
|
Suitable for reflow or hand soldering
Temperature range -55° to +125°C
Tolerance: ±20%
|
Specifications:
|
Value: 10µF
Volts DC: 10V
Package: A
|
NOTE:
|
|
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 20V, 4.7uF, Pack of 10SMD Tantalum Capacitor
Features:
|
Suitable for reflow or hand soldering
Temperature range -55° to +125°C
Tolerance: ±20%
|
Specifications:
|
Value: 4.7µF
Volts DC: 20V
Package: B
|
NOTE:
|
|
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 16V, 4.7uF, Pack of 10SMD Tantalum Capacitor
Features:
|
Suitable for reflow or hand soldering
Temperature range -55° to +125°C
Tolerance: ±20%
|
Specifications:
|
Value: 4.7µF
Volts DC: 16V
Package: A
|
NOTE:
|
|
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 25V, 2.2uF, Pack of 10SMD Tantalum Capacitor
Features:
|
Suitable for reflow or hand soldering
Temperature range -55° to +125°C
Tolerance: ±20%
|
Specifications:
|
Value: 2.2µF
Volts DC: 25V
Package: B
|
NOTE:
|
|
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 20V, 2.2uF, Pack of 10SMD Tantalum Capacitor
Features:
|
Suitable for reflow or hand soldering
Temperature range -55° to +125°C
Tolerance: ±20%
|
Specifications:
|
Value: 2.2µF
Volts DC: 20V
Package: A
|
NOTE:
|
|
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 35V, 1.0uF, Pack of 10SMD Tantalum Capacitor
Features:
|
Suitable for reflow or hand soldering
Temperature range -55° to +125°C
Tolerance: ±20%
|
Specifications:
|
Value: 1µF
Volts DC: 35V
Package: A
|
NOTE:
|
|
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Tantalum Chip Capacitor - 35V, 0.47uF, Pack of 10SMD Tantalum Capacitor
Features:
|
Suitable for reflow or hand soldering
Temperature range -55° to +125°C
Tolerance: ±20%
|
Specifications:
|
Value: 0.47µF
Volts DC: 35V
Package: A
|
NOTE:
|
|
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 10V, 1.0uF, Y5V, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 10V
Voltage Coefficient: Y5V
Value: 1µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 16V, 0.47uF, Y5V, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 16V
Voltage Coefficient: Y5V
Value: 0.47µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 25V, 0.22uF, Y5V, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 25V
Voltage Coefficient: Y5V
Value: 0.22µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 25V, 0.1uF, Y5V, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 25V
Voltage Coefficient: Y5V
Value: 0.1µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.1uF, X7R, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.1µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.047uF, X7R, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.047µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.047uF, Y5V, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.047µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.01uF, Y5V, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.01µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.0047uF, X7R, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.0047µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.0022uF, X7R, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.0022µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.001uF, X7R, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.001µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 470pF, X7R, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 470pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 330pF, X7R, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 330pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 270pF, X7R, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: X7R ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 270pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 220pF, X7R, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 220pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 100pF, NPO, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 100pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 47pF, NPO, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 47pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 33pF, NPO, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 33pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 27pF, NPO, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 27pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 22pF, NPO, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 22pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 18pF, NPO, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 18pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 15pF, NPO, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 15pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 12pF, NPO, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 12pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 10pF, NPO, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 10pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 5.0pF, NPO, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 5pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 1.0pF, NPO, 0603, Reel of 4,000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 1pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 10V, 1.0uF, Y5V, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 10V
Voltage Coefficient: Y5V
Value: 1µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 16V, 0.47uF, Y5V, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 16V
Voltage Coefficient: Y5V
Value: 0.47µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 25V, 0.22uF, Y5V, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 25V
Voltage Coefficient: Y5V
Value: 0.22µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 25V, 0.1uF, Y5V, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.1µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.1uF, X7R, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.1µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.047uF, X7R, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.047µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.047uF, Y5V, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.047µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.01uF, Y5V, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.01µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.0047uF, X7R, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.0047µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.0022uF, X7R, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.0022µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.001uF, X7R, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.001µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 470pF, X7R, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 470pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 330pF, X7R, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 330pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 270pF, X7R, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: X7R ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 270pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 220pF, X7R, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 220pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 100pF, NPO, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 100pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 47pF, NPO, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 47pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 33pF, NPO, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 33pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 27pF, NPO, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 27pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 22pF, NPO, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 22pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 18pF, NPO, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 18pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 15pF, NPO, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 15pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 12pF, NPO, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 12pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 10pF, NPO, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 10pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 5.0pF, NPO, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 5pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 1.0pF, NPO, 0603, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 1pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 1.0uF, Y5V, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: NPO ±10%, X7R ±10%, Y5V +80% / -20%
Temperature range: -55° to +125°C NPO & X7R, -30° to +85°C Y5V
|
Specifications:
|
Voltage: 16V
Voltage Coefficient: Y5V
Value: 1µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.47uF, Y5V, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: NPO ±10%, X7R ±10%, Y5V +80% / -20%
Temperature range: -55° to +125°C NPO & X7R, -30° to +85°C Y5V
|
Specifications:
|
Voltage: 16V
Voltage Coefficient: Y5V
Value: 0.47µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.39uF, Y5V, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: NPO ±10%, X7R ±10%, Y5V +80% / -20%
Temperature range: -55° to +125°C NPO & X7R, -30° to +85°C Y5V
|
Specifications:
|
Voltage: 16V
Voltage Coefficient: Y5V
Value: 0.47µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.22uF, Y5V, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: NPO ±10%, X7R ±10%, Y5V +80% / -20%
Temperature range: -55° to +125°C NPO & X7R, -30° to +85°C Y5V
|
Specifications:
|
Voltage: 25V
Voltage Coefficient: Y5V
Value: 0.22µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.1uF, Y5V, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.1µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.01uF, X7R, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.1µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.0047uF, X7R, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.047µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.0047uF, Y5V, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.047µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.0033uF, Y5V, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.033µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.01uF, Y5V, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.01µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.0068uF, X7R, 0805, Reel of 4000Tolerance: ±10%
Temperature range: -55° to +125°C
Specifications
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.0068µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.0047uF, X7R, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.0047µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.0022uF, X7R, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.0022µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.001uF, X7R, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.001µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 680pF, X7R, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 680pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 470pF, X7R, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 470pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 330pF, X7R, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 330pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 270pF, X7R, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 270pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 220pF, X7R, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 220pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 100pF, NPO, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 100pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 68pF, NPO, 0805, Reel of 4000Tolerance: ±10%
Temperature range: -55° to +125°C
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 68pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 47pF, NPO, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 47pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 3pF, NPO, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 33pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 27pF, NPO, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 27pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 22pF, NPO, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 22pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 18pF, NPO, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 18pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 15pF, NPO, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 15pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 12pF, NPO, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 12pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 10pF, NPO, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 10pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 5.0pF, NPO, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 5pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 3.9pF, NPO, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 3.9pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 2.7pF, NPO, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 2.7pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 1.0pF, NPO, 0805, Reel of 4000SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 1pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 16V, 1.0uF, Y5V, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: NPO ±10%, X7R ±10%, Y5V +80% / -20%
Temperature range: -55° to +125°C NPO & X7R, -30° to +85°C Y5V
|
Specifications:
|
Voltage: 16V
Voltage Coefficient: Y5V
Value: 1µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 16V, 0.47uF, Y5V, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: NPO ±10%, X7R ±10%, Y5V +80% / -20%
Temperature range: -55° to +125°C NPO & X7R, -30° to +85°C Y5V
|
Specifications:
|
Voltage: 16V
Voltage Coefficient: Y5V
Value: 0.47µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 25V, 0.39uF, Y5V, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: NPO ±10%, X7R ±10%, Y5V +80% / -20%
Temperature range: -55° to +125°C NPO & X7R, -30° to +85°C Y5V
|
Specifications:
|
Voltage: 16V
Voltage Coefficient: Y5V
Value: 0.47µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 25V, 0.22uF, Y5V, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: NPO ±10%, X7R ±10%, Y5V +80% / -20%
Temperature range: -55° to +125°C NPO & X7R, -30° to +85°C Y5V
|
Specifications:
|
Voltage: 25V
Voltage Coefficient: Y5V
Value: 0.22µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.1uF, Y5V, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.1µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.1uF, X7R, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.1µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.047uF, X7R, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.047µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.047uF, Y5V, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.047µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.033uF, Y5V, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.033µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.01uF, Y5V, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: +80% / -20%
Temperature range: -30° to +85°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.01µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.0068uF, X7R, 0805, Pack of 10Tolerance: ±10%
Temperature range: -55° to +125°C
Specifications
|
Voltage: 50V
Voltage Coefficient: Y5V
Value: 0.0068µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.0047uF, X7R, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.0047µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.0022uF, X7R, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.0022µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 0.001uF, X7R, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 0.001µF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 680pF, X7R, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 680pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 470pF, X7R, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 470pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 330pF, X7R, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 330pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 270pF, X7R, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 270pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 220pF, X7R, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: X7R
Value: 220pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 100pF, NPO, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 100pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 68pF, NPO, 0805, Pack of 10Tolerance: ±10%
Temperature range: -55° to +125°C
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 68pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 47pF, NPO, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 47pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 33pF, NPO, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 33pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 27pF, NPO, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 27pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 22pF, NPO, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 22pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 18pF, NPO, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 18pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 15pF, NPO, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 15pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 12pF, NPO, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 12pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 10pF, NPO, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 10pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 5.0pF, NPO, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 5pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 3.9pF, NPO, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 3.9pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 2.7pF, NPO, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 2.7pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Chip Capacitor - 50V, 1.0pF, NPO, 0805, Pack of 10SMD Chip Capacitor
Features:
|
Tolerance: ±10%
Temperature range: -55° to +125°C
|
Specifications:
|
Voltage: 50V
Voltage Coefficient: NPO
Value: 1pF
|
|
NOTE:
Please note different part numbers for OEM reels. Please contact us for OEM reel pricing.
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.0M, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 910k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 820k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 750k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 680k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 620k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 560k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 510k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 470k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 430k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 390k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 360k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 330k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 300k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 270k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 240k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 220k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 200k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 180k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 160k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 150k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 130k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 120k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 110k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 100k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 91k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 82k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 75k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 68k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 62k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 56k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 51k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 47k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 43k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 39k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 36k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 33k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 30k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 27k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 24k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 22k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 20k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 18k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 16k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 15k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 13k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 12k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 11k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 10k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 9.1k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 8.2k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 7.5k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 6.8k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 6.2k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 5.6k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 5.1k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 4.7k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 4.3k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 3.9k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 3.6k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 3.3k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 3.0k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 2.7k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 2.4k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 2.2k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 2.0k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.8k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.6k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.5k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.3k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.2k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.1k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.0k, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.0M, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 910k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 820k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 750k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 680k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 620k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 560k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 510k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 470k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 430k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 390k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 360k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 330k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 300k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 270k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 240k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 220k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 200k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 180k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 160k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 150k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 130k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 120k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 110k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 100k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 91k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 82k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 75k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 68k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 62k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 56k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 51k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 47k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 43k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 39k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 36k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 33k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 30k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 27k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 24k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 22k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 20k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 18k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 16k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 15k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 13k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 12k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 11k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 10k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 9.1k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 8.2k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 7.5k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 6.8k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 6.2k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 5.6k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 5.1k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 4.7k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 4.3k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 3.9k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 3.6k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 3.3k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 3.0k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 2.7k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 2.4k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 2.2k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 2.0k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.8k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.6k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.5k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.3k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.2k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.1k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 910R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 820R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 750R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 680R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 620R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 560R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 510R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 470R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 430R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 390R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 1.0k, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 910R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 820R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 750R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 680R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 620R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 560R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 510R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 470R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 430R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 390R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 360R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 330R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 300R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 270R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 240R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 220R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 200R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 180R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 160R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 150R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 130R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 120R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 110R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 100R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 91R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 82R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 75R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 68R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 62R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 56R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 51R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 47R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 43R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 39R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 36R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 33R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 30R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 27R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 24R, 1206, Pack of 10SMD 1% Metal Film Resistor. Pack of 10
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 360R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 330R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 300R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 270R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 240R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 220R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 200R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 180R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 160R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 150R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 130R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 120R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 110R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 100R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 91R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 82R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 75R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 68R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 62R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 56R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 51R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 47R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 43R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 39R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 36R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 33R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
13/05
|
SMD Metal Film Resistor - 0.25W, 30R, 1206, Reel of 5,000SMD 1% Metal Film Resistor. Reel of 5000
Features
|
• High grade thick film metal glazed ceramic body
• Suitable for reflow or hand soldering
• Temperature range -55° to +125°C
• Temperature co-efficient ±100 ppm/°C
• Tolerance ±1%
• 0.25W rated
|
SMD Resistor Value Markings:
|
• 0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.
• 0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000Ohm or 150KOhm
|
|
|
|
|
Previous Page
|
Next Page
|
|
