NoBrand Micro Relay - 5V DC Coil, 1.0A, DPDT, PCB Mount

[Large image available]

Product May Vary From Image

Part No:

115316

Brand:

NoBrand

Manuf No:

S4147

Usually Ships:

No Longer Available More info

Ship Weight:

0.0065 KG Details

Product Description

Fully sealed construction (immersion cleanable).

Specifications:

Max voltage: 250V AC, 220V DC
Max current: 0.5A AC, 1A DC
Max VA (Watts): 125VA (30W)
Contact material: Silver Palladium
Coil resistance: 167Ω
Max coil power: 200mw
Insulation resistance: >1000MΩ @ 500V DC
Dielectric strength (for 1 min):
1500V AC between open contacts
1500V AC between coil & contact
Electrical life: 200,000 operations 1A 24V
Mechanical life: 10 million operations
Dimensions: ˜10W x 20L x 15.5H mm

Product Warranty

1 Year Return to Base
