NoBrand 12V Sealed Lead Acid Battery - 57Hx97Lx43W, 1.2Ah

[Large image available]

Product May Vary From Image

Part No:

115283

Brand:

NoBrand

Manuf No:

S5075B

Usually Ships:

No Longer Available More info

Ship Weight:

0.58 KG Details

Product Description

Premium grade, long life, maintenance free sealed lead acid batteries. Cells are fully sealed to prevent leakage of electrolyte. Ideally suited for security alarm panels, telecommunications equipment, camcorder packs, medical equipment, computers, emergency lighting, fire systems and UPS’s. Connection tabs accept 4.8mm female spade connectors.

Physical Specification (mm)

L: 97
W: 43
H (Total): 57
Weight: 0.58kg

Electrical Specification

Capacity
20 hour rate (0.065A): 1.3AH
10 hour rate (0.11A): 1.1AH
5 hour rate (0.20A): 1.0Ah
1 hour rate (0.78A): 0.78AH

Capacity affected by temperature
40Deg.C: 105%
20Deg.C: 100%
0Deg.C: 85%

Constant voltage charge
Cycle
Initial charging current less than 0.39A.
Voltage 14.4V-15V @ 20Deg.C.
Temperature Coefficient -30mV/Deg.C

Standby
Voltage 13.5V-13.8V @ 20Deg.C
Temperature Coefficient -20mV/Deg.C

Product Warranty

1 Year Return to Base
